Sauna

Wood





There is nothing more Finnish than sauna; many locals think you can’t grasp Finland or its culture without bathing in one. A Drop sauna is a perfect addition to both summer cottages and home patios, just like other iconic Drop products. This turnkey outdoor sauna is ready to transform your space effortlessly. All it takes is an electrician and a flat spot to set it up.

You can choose the sauna either with a convenient electric heater or with a wood-burning stove for your ultimate relaxation.



Get an offer

Technical details
Contents of the package
Additional info
Maintenance
FAQ

• Builgind material is CLT (Cross-Laminated Timber)

• Exterior walls treated with black/clear wood stain or covered with light paint

• Sauna walls and benches feature neutral sauna wax, while the floor is treated with floor oil. Window wall is tinted to match the exterior walls

• Door made of CLT, a lock, a long black handle and a roller latch

• Roof covered with black bitumen and black edge plates

• Electrically heated Narvi Velvet Electric 9kW heater or wood-burning Juup Iiivari artisan stove

• Indirect lighting embedded along the back wall and ceiling with led-stripes

• Subfloor with slope towards a floor gap, serving as a floor drain

• Natural ventilation with inlet and exhaust

• Spacious benches, accommodating up to five sauna-goers

• Weight approximately 2000 kg

• Dimensions 230 x 230 x 230 cm (+ 10 cm base)

• Guarantees: structural CLT 10 years, Electric Huum Cliff heater 5 years, Wooden Juup Iivari stove 10 years



Measurement images ›

• Design: drawings for the sauna: floor, facade, sectional drawings, CLT element design, electrical design and production design.

• Exterior walls: CLT 100mm SURFACE CLT 100mm

• CLT 100mm, 2 parts + subfloor treated spruce 48X98

• Boards: CLT 100mm

• Front window frame: CLT 100mm machined with teardrop shaped opening according to drawings. Façades: colourless moulding as primer, surface treatment with tinted ballast. Colours: black, colourless and opaque white.

• Roof: black bituminous roofing (base and top felt), black edging tiles.

• Exterior door: fluted wooden door CLT 60mm Hide hinge TE 340 3D F1 2pcs Exterior door locking: lock frame Abloy LC102 + iron + key slot Abloy Easy CY001J black Exterior door puller oak handle Pillow 20233

• Window: insulating glass element 2k tempered.

• Finish: floors: CLT treated with Tikkurila Supi floor oil

• Surface treatment: walls, ceilings and ceilings: CLT treated with Tikkurila Supi sauna wax (10% whitewash)

• Heater: Huum Cliff 9kw + stones 5-10cm + control centre UKU local Glass

• Ventilation. Supply air through a floor recess, exhaust air through a hatch in the wall.

• Water control: pouring the CLT subfloor slab into a gap in the floor.

• Electricity: group control panel, power supply and connection to heater and lighting. Includes switch 1-piece ABB impressivo black and the necessary transformer. Power plug 3x16A. PLEASE NOTE! Electrical installation in accordance with Finnish regulations and electricity network. Separately on request, instructions for converting the system to 1-phase.

• Lighting: LED strip on the ceiling, on the back wall: Superled PRO TUNNELMA LED strip 4.3W/m, 24V, IP65 Superled Dimmable LED transformer NAPA, 12V/24V, 5-30W Superled LED profile with cover, 16x7mm, silver

• Accessories: fixing accessories, sealing compounds and sealing tapes

• Packaging: corner protectors and shrink-wrap (white)

The sauna must be installed on a flat, load-bearing surface (bearing capacity 500kg/m2, tolerance +-2mm) and ensure that the drainage from the floor works as planned. The fit is also important for the operation of the door.



Examples of the platform:

Compacted, rust-free gravel bed

Concrete slab on a compacted gravel bed

Concrete, ingot, or steel pillars on a compacted gravel bed (at least 4 in the corners)



Instructions and warrant



• The water ceiling must be inspected regularly at least once a year and dirt and impurities must be removed

• Windows and doors should be cleaned regularly

• Ventilation and drying of the interior must be taken care of after use

• The platforms and the floor should be dried from water with a spatula or something similar after each use

• It is recommended to use seat covers

• The inner surfaces should be cleaned regularly and the condition of the silicones should be checked. Silicones must be renewed at least every 2 years

• The exterior surfaces of the sauna are recommended to be re-treated according to Teknos' instructions with a water-based cleaning agent https://www.teknos.com/fi-FI/tuotteet/woodex-aqua-classic/

 when the surface looks worn and the treatment agent comes off when brushing the surface, e.g. with a root brush. Surfaces exposed to the sun wear out faster than shaded surfaces and the surface lives longer. Before processing, loose matter, dirt and dust are removed from the surface with a steel or root brush. After this, it is recommended to wash before re-treatment. Surfaces can be service painted with Teknos water- and solvent-thinned sealants, as well as cover protectors and house paints.

• The inner surfaces are recommended to be treated again in accordance with Tikkurila's instructions (below) when the surface has worn so that the water-repellent property has worn off and the surface begins to absorb moisture. Before the maintenance treatment, it is recommended to wash / sand the old substance so that the substance can be absorbed into the treated wood.



See the applicable products and handling instructions at the following links. Floor: https://tikkurila.fi/tuotteet/supi-lattiaoljy

Walls and ceilings: https://tikkurila.fi/tuotteet/supi-saunavaha

Where should I install the sauna/ lodge and what kind of surface does it require?

The sauna must be installed on a flat, load-bearing surface (bearing capacity 500kg/m2, tolerance +-2mm) and ensure that the drainage from the floor works as planned. The fit is also important for the operation of the door.



Examples of the platform:

Compacted, rust-free gravel bed

Concrete slab on a compacted gravel bed

Concrete, ingot, or steel pillars on a compacted gravel bed (at least 4 in the corners)



Which temperature will the sauna reach in one hour?

With electric stove the sauna heats to 70-75 celsius in one hour.

With wood heated stove the sauna heats to 80 celcius in one hour.



What permits does the sauna/lodge require?

Contact your local building authority to find out the permit matters in your own area.



How should I maintain the sauna?

• The water ceiling must be inspected regularly at least once a year and dirt and impurities must be removed

• Windows and doors should be cleaned regularly

• Ventilation and drying of the interior must be taken care of after use

• The platforms and the floor should be dried from water with a spatula or something similar after each use

• It is recommended to use seat covers

• The inner surfaces should be cleaned regularly and the condition of the silicones should be checked. Silicones must be renewed at least every 2 years

• The exterior surfaces of the sauna are recommended to be re-treated according to Teknos' instructions with a water-based cleaning agent https://www.teknos.com/fi-FI/tuotteet/woodex-aqua-classic/

 when the surface looks worn and the treatment agent comes off when brushing the surface, e.g. with a root brush. Surfaces exposed to the sun wear out faster than shaded surfaces and the surface lives longer. Before processing, loose matter, dirt and dust are removed from the surface with a steel or root brush. After this, it is recommended to wash before re-treatment. Surfaces can be service painted with Teknos water- and solvent-thinned sealants, as well as cover protectors and house paints.

• The inner surfaces are recommended to be treated again in accordance with Tikkurila's instructions (below) when the surface has worn so that the water-repellent property has worn off and the surface begins to absorb moisture. Before the maintenance treatment, it is recommended to wash / sand the old substance so that the substance can be absorbed into the treated wood.
